The Safe, No-Solvent Solution to Cleaning Parts Automatically
CUDA Top Load Automatic Parts Washers
Cuda 2412 Series
Cuda’s 2412 series of parts washers is an attracitve entry-level aqueous parts washer. The washer has a 250-lb. load capacity, 24″ diameter rotating turntable, 25 gal sump capacity, automatic oil skimmer, and low water shutdown. These units are available with either a 1/2 hp or 2 hp motor. Operating temperature of 150-170 degrees F. Machine dimensions are 41″L x 35″W x 45″H.
Machine is available in Stainless Steel.
These units are ETL-certified to UL-1776 Safety Standards.
Warranty: Overall Unit – 1 Year
OPTIONS: Automatic Water Fill, Pneumatic Power Brush, Detail Brush with Pump, Oil Drain Container, Skimmer Timer 24/7, Hour Meter, Pressure Gauge, Heater Timer, Heater & Skimmer Timer
| HP | Voltage / PH | Elec Heater (kw) | Working Height |
|---|---|---|---|
|
1/2 |
115/1 208/1 230/1 |
1.8 (115V Units) 4.5 (208-230V Units) |
12″ |
|
2 |
208/1 230/1 208/3 230/3 460/3 |
4.5 (Single Phase) 6.0 (Three Phase) |
12″ |
Cuda 2216 Series
The Cuda Top Load 2216 Series is a compact aqueous parts washer with a 500-lbs load capacity, 22″ turntable, 23 gal sump capacity, automatic oil skimmer and low water shutdown. These units have a 1HP pump motor producing 28 GPM@30 PSI. Operating temperature of 150-170 degrees F. Machine dimensions are 42″L x 32″W 52″H.
Machine is available in Stainless Steel.
Units are ETL-certified to UL-1776 Safety Standards.
Warranty: Overall Unit – 1 Year
OPTIONS: Automatic Water Fill, Pneumatic Power Brush, Detail Brush with Pump, Oil Drain Container, Heater Timer 24/7, Hour Meter, Pressure Gauge
| HP | Voltage / PH | Elec Heater (kw) | Working Height |
|---|---|---|---|
|
1 |
115/1 208/1 230/1 208/3 230/3 460/3 575/3 |
2 (115V Units) 4.5 (208-230V-1ph Units) 6 (Three Phase) |
16″ |
|
2 |
208/1 230/1 208/3 230/3 460/3 |
4.5 (Single Phase) 6.0 (Three Phase) |
16″ |
Cuda 2518 Series
The 2518 Cuda Top Load Washer is at the top of our line with ruggedness and automation throughout. It comes standard with a time-tested chain drive assembly, virtually maintenance-free vertical seal-less pump, and disc oil skimmer that can be automated for convenience in disposing of oil. Unit comes with a 3HP motor, 500-lbs load capacity, 25″ turntable, 50 GPM@45PSI pump, 50 gal sump capacity, 6 kw heater, automatic oil skimmer, and low water shutdown. Operating temperature of 150-170 degrees F. Machine dimensions are 51″L x 40″W 50″H.
Machine is available in Stainless Steel.
Units are ETL-certified to UL-1776 Safety Standards.
Warranty: Overall Unit – 1 Year
OPTIONS: Automatic Water Fill, Pneumatic Power Brush, Detail Brush with Pump, Oil Drain Container, Heater Timer 24/7, Heater & Skimmer Timer 24/7, Hour Meter, Pressure Gauge
| HP | Voltage / PH | Working Ht. |
|---|---|---|
|
3 |
208/1 230/1 208/3 230/3 460/3 575/3 |
18″ |
Data effective January 1, 2021. Specifications and product descriptions subject to change without notice.
